Silent Tower is a product built entirely on Heat pipe technology. Three 6mm diameter copper rods mounted on a 5mm high copper plate measuring 5.6x6cm at the base are in contact at both ends with exactly 59 aluminum plates lined up one after the other at the top. The fact that the rods are facing the base at exactly right angles fulfills the most ideal usage conditions of the Heat pipe technology. In this way, the heated air reaches the upper part as quickly as possible, condenses here and moves to the lower part again. Of course, the situation in the safe is a little different.
Thermaltake Silent Tower
The aluminum plates on the Silent Tower are lined up, leaving about 2mm of air channels between them. The top and sides are covered with blue aluminum plates with the Tt logo on it for proper airflow. In this way, the air flow entering from the front is quickly thrown out by taking the heat on the plates.
Thermaltake Silent Tower: Aluminum Plates
One of the most important players in this whole system is the 90mm fan at the front with a noise ratio of 21dba and a speed of 2500RPm. This fan, which has a very solid structure, has 4 air channels on the sides, which is unusual. Thanks to these channels, it is planned that the fan blades collect a slightly higher air flow. In this state, the fan can provide 52.24 CFM of airflow.
Thermaltake Silent Tower: Assembly
It is possible to install a second fan on the Silent Tower by purchasing the Thermaltake Combo Cool A2013 for an average of $15. In this way, the air flow between the aluminum channels can be realized more intensely; The airflow entering from the front is slowed down a bit due to friction while passing between the plates. Thanks to a second fan to be placed at the outlet part of the air flow, a vacuum system is created in this part, making it possible to realize the air flow with maximum efficiency. Therefore, this situation causes the heat pipe rods to be kept cooler, causing a few degrees drop in temperature level and a slightly higher sound rate.
2500RPm Although the noise level for the running fan is 21dba, the aluminum plates above the airflow cause the sound level to increase considerably. Since we do not have the opportunity to measure the sound level, we will compare the sound rates of the products in the review with each other. In this case, Silent Tower does not present a very encouraging situation. Compared to the original intel cooling, the sound rate of the Silent Tower is significantly higher…
Thermaltake Silent Tower: Copper Base
It is difficult to say that the surface of the copper plate in the base is sufficiently ground. caterpillar on the surface
